Maha – Multi cylinder lifts ES DUAL 4/3 RS 14.0

TRUCKLIFT | Multi-Post Lifting System four lifting units with S cover


Description:

Robust, hard chrome-plated lifting posts with high bending strength
Torsion protection due to double cylinders
Corrosion-resistant hydraulic piston, because it plunges into the hydraulic oil with every stroke
Medium-pressure hydraulic unit installed in a space-saving manner directly on the lifting units
Very quiet pump and very quiet electric motor in corrosion-resistant submerged oil version, with organic oil as an option
Optimum safety in operation owing to system with two separate hydraulic circuits and additional electronic pressure/leak detection as standard
Electronic synchronisation for even lifting of the vehicle (as per EN 1493), regardless of the height of the lifting point on the vehicle
High level of operating comfort on the central control and programming unit thanks to two operating panels incl. text display relating to the operation of the lifting units and the raising of the lifting columns
High level of flexibility in use due to different operating modes
Group and individual operating modes enable quick and easy replacement of wheel and axle suspensions.
Automatic positioning program for storing and calling back up different vehicle lifting positions to save time when adjusting the movable lifting units
Portable control unit for convenient operation with 20 metre control line
Simple, integrated, pneumatically operated emergency lowering in the event of power failure
Flexible and custom selectable post distance due to individual cassettes
Robust roller cover systems with travel drive made of aluminium profile segments with non-slip surface, connected with aluminium joints
Narrow roller cover with on-ground support cross-beam, can be driven over with wheel loads of up to 4000 kg


Standard Delivery:

Four lifting units, three of which are movable, with S roller cover
Support cross-beam in anthracite grey (RAL 7016)
Vehicle support sliders are not included in the scope of delivery
Switch cabinet and portable operating panel
Pre-assembled cable harnesses per lifting unit, length: 30 m
Wiring and mounting materials
Installation cassette / installation frame not included in the scope of delivery
Lockable main switch
Operating manual and test log
EC CE declaration of conformity
